Megger PAT350 PAT Tester
- Simple manual or automatic testing
- 230 V and 110 V operation
- Bond testing at 25 A,10 A and 200 mA
SKU
MEGPT5
MPN
1000-743
Almost identical to the Megger PAT320, the PAT350 has all of the same abilities + the ability to perform flash testing, making this ideal for use in workshops, manufacturing facilities and tool shops.
The PAT350 is a manual PAT tester - it doesn't include memory storage. If you're testing with this instrument, you'll need to jot down your results in a PAT logbook, or manually enter it into software such as SimplyPATs Manual.
With the PAT350, testing is much quicker thanks to an automatic testing mode. In this mode, the tester will automatically cycle through bond, insulation and operating tests. A dedicated manual mode is also included which gives the user control over bond test current, insulation test voltages and leakage test types.
Megger PAT350 PAT Tester Key Features
- Flash testing capability at 1.5 and 3kV
- Desktop-based use - bring appliances to the tester
- Automatic and manual testing procedures
- Simple push button operation
- Performs all common PAT procedures - Class I and Class II, IEC power leads, extension leads and portable RCD testing
- Full colour display
- Integrated QWERY keyboard
- 230/110V operation
- Bond testing at 25A, 10A and 200mA
- Differential, touch and substitute leakage testing
What's Included?
- Megger PAT350 PAT Tester
- Carrying Case
- Continuity/Earth Bond Lead
- Extension Lead Adaptor
- Flash Test Lead
- Screen Protector
£1,070.00
£1,284.00 inc vat
Only 1 in Stock:
Available Next Working Day*
Offers
FREE PAT Reference Card
- PAT Testing Reference Card 5th Edition - PAT-TEST-CARD, typically £5.00
Technical Information
Specification
Megger PAT350 Technical Specifications
| Electrical Supply Range | |
| 230V AC | 230V AC ±10% |
| 110V AC | 110V AC ±10% |
| Supply Measurement | |
| Voltage | ±2% ± 1V |
| Frequency | ±1% ± 0.1Hz |
| Bond Test | |
| Open Circuit Voltage | 9V AC ±10% ±0.1V (Supply: 230V 50Hz) |
| 10A Bond Test Current | 10A rms ±20% ±0.5A into 0.1Ω |
| 25A Bond Test Current | 25A rms ± 5% ± 0.5A into 0.1Ω |
| Earth Bond Resistance Accuracy | ±5% ± 3 digits (0 to 0.49Ω) ±5% ± 5 digits (0.5 to .99Ω) |
| Earth Bond Resistance Resolution | 10mΩ (0 to 1.99Ω) |
| Display Range | 0 to 1.99Ω |
| Bond Test Nulling | Up to 1.00Ω |
| Adjustable Test Duration | User selectable from 1 sec to 20 sec |
| Continuity Test | |
| Note | The continuity test is a DC test performed automatically in both positive and negative directions. The average of the two results is shown |
| Continuity Test Voltage | 4.0V DC -0% +10% (open circuit) |
| Continuity Test Current | 200mA -0% + 10% ± 5mA (into 2Ω load) |
| Continuity Resistance Accuracy | ±5% ±3 digits (0 to 0.49Ω) ±5% ±5 digits (0.5 to .99Ω) |
| Continuity Resistance Resolution | 10mΩ (1 to 19.99Ω) |
| Display Range | 0 to 19.99Ω |
| Continuity Test Nulling | Up to 9.99Ω |
| Test Duration | User selectable from 1 sec to 20 sec |
| Insulation Test | |
| Insulation Test Voltage | 250V DC -0%/+25% open circuit 500V DC -0%/+25% open circuit (500V DC across 0.5MΩ) |
| Insulation Resistance Accuracy (230V) | ±2% ±5 digits (0 to 19.99MΩ) ±5% ± 10 digits (20 to 99.99MΩ) |
| Insulation Resistance Accuracy (110V) | ±5 ±5 digits (0 to 10MΩ) |
| Insulation Resistance Resolution | 0.01MΩ (0.10 to 99.99MΩ) |
| Display Range | 0 to 99.99MΩ |
| Test Duration | User selectable from 1 sec to 1 minutes |
| Substitute Leakage Test | |
| Test Voltage | 40V AC ±10% |
| Test Frequency | Nominal mains 50/60Hz |
| Leakage Current Accuracy | ±5% ± 5 digits |
| Leakage Current Resolution | 0.01mA |
| Display Range | 0 to 19.99mA |
| Test Duration | User selectable from 1 sec to 1 minute Reading corrected to 230V + 10% or 110V +10% AC |
| Differential Leakage Current | |
| Test Voltage | Nominal mains 110V/230V AC |
| Test Frequency | Nominal mains 50/60Hz |
| Differential Leakage Current Accuracy | ±5% ± 5 digits |
| Differential Leakage Current Resolution | 0.01mA |
| Display Range | 0 to 19.99mA Reading corrected to 230V +10 % or 110V + 10% AC |
| Touch Current Test | |
| Test Voltage | Nominal mains 1150/230V AC |
| Test Frequency | Nominal mains 50/60Hz |
| Touch Current Accuracy | ±5% ±5 digits |
| Touch Current Resolution | 0.01mA |
| Display Range | 0 to 10mA |
| Test Duration | User selectable from 1 sec to 5 sec Reading corrected to 230V + 10% or 110V + 10% AC |
| Operational Test | |
| Test Voltage | Nominal mains 110V/230V AC |
| Accuracy | ±5% ±10 digits (0 to 99VA) ±5% ±50 digits (100 to 999VA) ±5% ±100 digits (1000 to 3700VA) |
| Resolution | 1VA (0 to 3700VA) |
| Display Range | 0 to 3.99KVA Reading corrected to 230V or 110V AC Results show load VA |
| Extension Lead Test | |
| Polartity Test Voltage | 12V |
| Polarity | Leak OK Live neutral S/C Live neutral reversed Live/neutral O/C |
| Flash Test | |
| Flash Test Voltage | 1500V AC nominal for class 1 3000V AC nominal for class 2 |
| Flash Test Current | <3.5mA short circuit @ 253V primary supply voltage |
| Flash Test Breakdown Current Accuracy | ±5% ± 5 digits |
| Flash Test Breakdown Current Resolution | 0.01mA |
| Display Range | 0 to 3.0mA |
| Test Duration | User-controlled |
| Portable RCD Test | |
| RCD Test Voltage | Nominal mains 110/230V |
| RCD Test Frequency | 50Hz |
| Test Current Accuracy | -8% to -2% (1/2 x I) ±2% to +8^ (1 x 1,5 x I) |
| Trip Time Accuracy | ±1% ±5 digits |
| Trip Time Resolution | 0.1ms |
| Display Range | 0 to 1999ms (1/2 x I) 0 to 300ms (1 x I) 0 to 40ms (5 x I) |
| Fuse Test | |
| Test Voltage | 3.3V |
| Warning | Audible Beep if fuse is ok |
